For quick and easy fixing of PV panels on vertical façades.

PV clip system

The fischer PV clip impresses with its versatility and functioning on diverse anchoring surfaces. Even demanding requirements on the façade are met. Constraints, as encountered with conventional PV clamps, are avoided. The PV panels are securely and mechanically attached thanks to the fischer PV clip. The concealed fixing opens the possibility of realizing comprehensive façade designs.

Варианти на продуктите

5 Варианти на продукта

Type

Width

Height

Thickness

Hole-ø

Slot

Разгледан(и) 5 от 5 вариант(а)

Advantages

The practical sliding nut enables quick and constraint-free installation.
The simple stainless steel plug-in system is highly weather-resistant thanks to the high corrosion protection class III.
Suitable for all types of framed PV panels with mounting holes.
The system enables fixing to various wall substrates and also to different substructures.
The modular system enables the construction of contiguous panel arrays with adjustable joint sizes.
The start/end clip can be used both as a start clip and as an end clip, thus minimizing the number of products required.
Pre-applied thread locker on screws.
Integrated potential equalisation.

Properties

Stainless steel with high corrosion protection class III.

Applications

PV clip for mounting PV panels on façades

Building materials

Various building substrates (concrete, wood, masonry, steel, trapezoidal sheet metal)
Various substructures (aluminum profiles, steel profiles, wooden battens)

Подробна информация за строителните материали можете да намерите в регистрационния документ.

Functionality

First panel:

Slide at least four sliding nuts FSMN II R onto the mounting holes on the back of the panel frame.
Apply a drop of threadlocker before screwing in the serrated screws.
Install at least two start/end clips FSMC S/E with one fischer serrated screw each on one side of the panel.
Install at least two middle clips FSMC M with one fischer serrated screw each on the opposite side of the panel.
Fix the start/end clips FSMC S/E to the building substrate using plugs, wood screws etc..
Fix the middle clips FSMC M to the building substrate using plugs, wood screws etc..

Middle panels:

Slide at least four sliding nuts FSMN II R onto the mounting holes on the back of the panel frame.
Apply a drop of threadlocker before screwing in the serrated screws.
Screw the fischer serrated screws into the sliding nuts on one side of the panel.
Install at least two middle clips FSMC M with one fischer serrated screw each on the opposite side of the panel.
Attach the screws to the previous panel using the lock-and-key principle and slide them in.
Fix the middle clips FSMC M to the building substrate using plugs, wood screws etc..

Last panel:

Slide at least four sliding nuts FSMN II R onto the mounting holes on the back of the panel frame.
Apply a drop of threadlocker before screwing in the serrated screws.
Screw the fischer serrated screws into the sliding nuts on one side of the panel.
Install at least two start/end clips FSMC S/E with one fischer serrated screw each on the opposite side of the panel.
Attach the screws to the previous panel using the lock-and-key principle and slide them in.
Fix the start/end clips FSMC S/E to the building substrate using plugs, wood screws etc..

Mounting Strip 1 Picture

1 / 10

Type	Start/end clip
Width ( W )	60 mm
Height ( H )	60 mm
Thickness ( T )	1,5 mm
Hole-ø ( D )	5,5 mm
Slot ( l x s )	9 x 15 mm
Perforated frame edge distance	17 - 26 mm
Thread	—
Amount	20 pcs
GTIN (EAN-Code)	4048962527872

Type	Middle clip
Width ( W )	110 mm
Height ( H )	60 mm
Thickness ( T )	1,5 mm
Hole-ø ( D )	5,5 mm
Slot ( l x s )	9 x 15 mm
Perforated frame edge distance	17 - 20 mm
Thread	—
Amount	50 pcs
GTIN (EAN-Code)	4048962527889

Type	Middle clip
Width ( W )	120 mm
Height ( H )	60 mm
Thickness ( T )	1,5 mm
Hole-ø ( D )	5,5 mm
Slot ( l x s )	9 x 15 mm
Perforated frame edge distance	20 - 26 mm
Thread	—
Amount	50 pcs
GTIN (EAN-Code)	4048962527896

Type	—
Width	—
Height	—
Thickness	—
Hole-ø	—
Slot	—
Perforated frame edge distance	—
Thread ( M )	M8
Amount	100 pcs
GTIN (EAN-Code)	4048962534399

Type	—
Width	—
Height	—
Thickness	—
Hole-ø	—
Slot	—
Perforated frame edge distance	—
Thread ( M )	M8
Amount	100 pcs
GTIN (EAN-Code)	4048962554816
